Solar High Mast Street Light
Suntech solar Energy enterprises offers a wide range of High Mast light as well as complete systems. We deal in innovative, quality and cost- competitive range of LED Solar High Mast lighting System.
| Technical Specifications: Solar High Mast Lights | ||||
| Description | 72W LED | 96W LED | 120W LED | 144W LED |
| LED Luminaire | 4X18W LED | 4X24W LED | 4X30W LED | 4X36W LED |
| Solar PV Module (Power) | 4X100Wp | 4X125Wp | 4X200Wp | 4X225Wp |
| Battery Capacity @ C/10 | 4X75AH | 4X100AH | 4X120AH | 4X150AH |
| Pole | G.I.Galvanized MS (7m) | G.I.Galvanized MS (7m + 1m) | ||
| Voltage | 12V | |||
| Charging Type | PWM | |||
| Cell | High efficiency Multi Crystalline Silicon Cells / Mono Crystalline Silicon Cells | |||
| Rigidity | Designed to with stand tough environment conditions | |||
| Battery Box | 100% Acid Proof / Polymer Battery Box / Metal Box | |||
| Charging Efficiency | <96% | |||
| Self Discharge | <2% per month at 27°C | |||
| LED Luminaire | ||||
| Driver Efficiency | 92% | |||
| World Class LEDs | from Japan/Germany | |||
| Lumen Efficiency / Watt | >120 Lumen/w | |||
| Rated Lamp Life (Avg.) hrs | More than 50,000 hrs | |||
| IP Class | IP 65/67 | |||
| Humidity | 95% | |||
| Power factor | 1 | |||
| Operating Temperature | 15°C to + 80°C | |||
| Dimmer | Programmable (Micro-Controller Based) | |||
| Autonomy | 3 Days | |||
| Protection | Open Circuit, Short Circuit Protection for Lamp, Over Charge & Deep Discharge, Over load, Reverse polarity, Reverse Flow | |||
| Indicators | Green Charging, Red Low Battery | |||
| Product Warranty | 2 Years Warranty complete System/** | |||
| Note: Also available on demand model 50W. | ||||
| Extra Features street light with camera, remote control, GPS system control, wi-fi. | ||||
| **More than 2 years warranty on customers demand. | ||||
